Used Combine Harvester Complete Threshing Cylinder

The Complete Threshing Cylinder: Core Component of a Combine Harvester

On a combine harvester, the threshing cylinder is a transverse drum with a standard diameter of about 600 mm, composed of multiple side plates holding between 6 and 8 threshing bars (ribbed bars). It strikes the crop against the concave (fixed perforated basket). Grains fall through the sieves, while the straw continues to the shakers for final separation.

The rotational speed is adjustable between 400 and 1,200 rpm via a hydraulically controlled belt variator to adapt to each crop type. A complete threshing cylinder includes the cylinder shaft, the side stars (side plates), the threshing bars, the mounting studs, the factory dynamic balancing, and — depending on the brand — the pulley or the drive variator. This technology equips the vast majority of European combine harvesters in use.

When to Replace Your Combine Harvester’s Complete Threshing Cylinder?

Several symptoms require intervention: vibrations at high speeds, significant wear on threshing bars (loss of ribs), broken side star, shaft cracks, end bearing play, or following major damage (large foreign object in the threshing drum). For older machines (Claas Dominator, Mega, Lexion 400, John Deere series 9000, Case IH 2188, MF 30/40, NH TX), new complete threshing cylinders are rare and costly. In this case, original used parts become the best technical and economic option.

Winter maintenance is the ideal time for diagnosis: remove the inspection hatch, check bars and studs, inspect the shaft, and anticipate ordering before the harvest peak in June-July.

Brands and Models of Complete Threshing Cylinders in Stock for Combine Harvesters

Our catalog covers the main ranges of combine harvesters distributed in France:

• Claas: Dominator (98, 108, 116, 118), Mega, Avero, Tucano 320 to 580, Lexion 450 to 580
• John Deere: Series 9000 WTS, W540, W550, T550, T560, T660
• New Holland: CX5.80 to CX8.90, TX (older models)
• Case IH: 2188 (traditional technology), 5088 (heritage)
• Massey Ferguson: Activa 7244, 7345; Beta; Centora 7370; MF series 30/40 (older)
• Deutz Fahr: 4080, 5650, 5670, 6040, 6050, 6060
• Laverda: M300, M400, AREA, REV, LCS

Each complete threshing cylinder undergoes our rigorous inspection process: careful disassembly, cleaning, shaft verification, wear check on bars and studs, condition of side stars, bearing integrity, and weld inspection.

Why Choose Original Manufacturer Used Parts?

A complete threshing cylinder is a dynamically balanced part: its original manufacture includes precise balancing to reduce vibrations at high speed. An original part, dismantled from a properly functioning machine, retains this factory balancing and geometry. This is a decisive technical advantage over any remanufactured or rebuilt alternative assembled from mixed parts.

Economically, original used parts offer a significant reduction in replacement cost compared to new ones. For ETA and CUMA managing multiple combines, it is also a fleet management tool: keep reliable machines in service without overinvesting beyond the machine's residual value.

Our Expertise: Dismantling and Inspecting Threshing Cylinders

Since 1945, TMC Bejenne has been practicing industrial deconstruction of agricultural equipment. Each recovered combine harvester is methodically dismantled in our workshops, with part marking and traceability by original machine number. The complete threshing cylinder is taken apart shaft by shaft, star by star, then inspected piece by piece.

Our technicians, former agricultural mechanics, identify defects (cracks, deformations, excessive play) that would render a part unsuitable for resale. Only approved parts enter our catalog.

Quote and Shipping for Your Complete Threshing Cylinder

Provide us with the brand, the exact model, the year, and the serial number of your combine harvester. A photo of the existing threshing cylinder and the manufacturer's reference speed up the search. Quotes within 24 hours, shipping within 24-48 hours depending on weight and dimensions. 15-day returns if the part is non-compliant.

4de Expert advice at 05 86 24 00 26 or request a quote online.
